数据结构-栈

数据结构:栈

栈是一种线性结构,它只能从一端添加元素,也只能从一端取出元素(这一端称之为栈顶)。
Stack这种数据结构用途很广泛,在计算机的使用中,大量的运用了栈,比如编译器中的词法分析器、Java虚拟机、软件中的撤销操作(Undo)、浏览器中的回退操作,编译器中的函数调用实现等等。

栈

本次使用单链表实现栈的基本操作,并用栈实现二进制转换十进制。

栈的创建和初始化

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
#include <stdio.h>
#include <stdlib.h>
#include <stdbool.h>

#define ERROR_CODE -108
#define EMPTY_CODE -109

typedef struct linklist
{
int number;
struct linklist *next;
}LINKLIST;

LINKLIST *init_list()
{
LINKLIST *head,*end;
head = (LINKLIST*)malloc(sizeof(LINKLIST));
end = head;
end->next = NULL;
return head;
}

在创建栈的时候引入了头文件<stdbool.h>,目的是引入了bool类型。
同时宏定义了两个出错代码,代表出错和栈为空。

判断栈为空

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
bool is_empty(LINKLIST *list)
{
if (list == NULL )
{
printf("stack is not exit!\n");
exit(EMPTY_CODE);
}
if (list->next == NULL)
{
return true;
}


return false;
}

如果只有一个头节点则栈为空

入栈

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
int push(LINKLIST *list,int number)
{
LINKLIST *node;
if (list == NULL)
{
return ERROR_CODE;
}

while (list->next!=NULL)
{
list = list->next;
}

node = (LINKLIST*)malloc(sizeof(LINKLIST));
node->number = number;
list->next = node;
node->next = NULL;
return 0;
}

采用尾插法完成入栈操作

出栈

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
int pop(LINKLIST *list)
{
int number;

if (list == NULL)
{
return ERROR_CODE;
}

if (is_empty(list))
{
return EMPTY_CODE;
}

while (list->next->next != NULL)
{
list = list->next;
}

number = list->next->number;
free(list->next);
list->next = NULL;

return number;
}

每次出栈从链表尾弹出一个节点

删除栈

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
int del(LINKLIST **list)
{
if (*list == NULL)
{
return ERROR_CODE;
}
while ((*list)->next != NULL)
{
pop(*list);
}

free(*list);
*list = NULL;

}

将所有节点出栈,并删除头结点


二进制转换十进制

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
int main()
{
int i = 0;
char c;
int sum = 0;
LINKLIST *list = init_list();

printf("请输入一个二进制数,输入#表示结束!\n");
scanf("%c", &c);
while (c != '#')
{
push(list, c);
scanf("%c", &c);
}
getchar();

while (list->next != NULL)
{
sum = sum+(pop(list)-48)*pow(2,i);
i++;
}

printf("转化为十进制数为:%d\n",sum);
return 0;
}

值得注意的是,直接gcc编译时会报链接错误,需要链接math库即 gcc stack.c -lm 具体原因不明

栈的创建和操作沿用之前的函数,只需要加一个main()并引入头文件<math.h>函数即可
首先将键盘上的每个字符入栈(偷懒了没做01字符的判断),然后每出栈一个字符就进行幂运算。
出栈得到的是ASCII码,0对应的ASCII码为48所以减去48就可以得到实际的数
